M8 5pin Custom 90 Degree Or Straight Male/Female Connector

The M8 5-pin connector is a specific variant of the M8 connector family, distinguished by its configuration with five pins. Like other M8 connectors, it maintains the same robust and compact design, making it ideal for applications where space is limited, and reliable connections are critical. The M8 5-pin connector features a circular housing with a threaded coupling nut for secure and easy mating. Within this housing, there are five pins arranged in a circular pattern. These pins are responsible for transmitting electrical signals, power, or a combination of both, depending on the application's requirements. One of the notable features of the M8 5-pin connector is its versatility. It is commonly used in a wide range of industries and applications, including industrial automation, sensor networks, robotics, and automotive. The five-pin configuration allows for more complex connections than the standard 3-pin or 4-pin M8 connectors, making it suitable for applications that require additional functionality or signal diversity. Furthermore, M8 5-pin connectors are designed to withstand challenging environmental conditions. Many variants are built to be waterproof and dustproof, often meeting IP67 or higher ratings. This level of protection ensures that the connector can perform reliably even in harsh and demanding environments.

Products Details

We are the Verified Supplier, has the professional R&D team.          Supply the high quality products all over the world.
Send Inquiry to get more information and discount.
Item Name
M8 connector
Number of contacts
3; 4; 5; 6; 8
Connector locking system
Screw
Termination
Screw, Solder
Wire guage
Max. 0.25mm²; Max. 0.25mm²; Max. 0.25mm²; Max. 0.25mm²; Max. 0.14mm²
Cable outlet
3.5-5 mm
Degree go protection
IP67
Mechanical operation
>100 mating cycles
Temperature range
(-25°-85°)
Rated voltage
60V; 30V; 30V;30V; 30V
Rated im pulse voltage
1500V;1500V; 800V; 800V; 800V
Pollution degree
3
Overvoltage categorie
Material group
Rated current(40°)
3A; 1.5A
Contact resistance
<=3mΩ (Gold)
Material of contact
Brass
Contact plating
Gold
Material of contact body
PA
Material of housing
PA
Codding key
A; B
